Residential Load Calculation Handbook for Beginners

Can you size a residential service without guessing?

Most electrical training explains what a load calculation is. Almost none walks you through one from the first tape measure to the finished breaker. This handbook does, in plain language, one step at a time, with every number shown.

You start with volts, amperes, and volt-amperes, then build up through the five load groups that make up every dwelling calculation: general lighting, fixed appliances, the range, the dryer, and heating versus cooling. By Chapter 8 you are running complete standard-method calculations. By Chapter 14 you are working multifamily buildings and evaluating whether an existing service will carry a vehicle charger.

Written in second person for apprentices, trade students, licensing exam candidates, and working electricians who want the method to finally click.

Inside you will find:

• Complete worked calculations, not fragments. Five full examples carried start to finish, including a gas house, an all-electric house by both permitted methods, a large home near a service boundary, an eight-unit building, and an addition to an existing service.
• Over 200 figures, tables, and diagrams. Every demand factor illustrated, every worksheet shown filled in as well as blank.
• Both calculation methods, side by side. Learn when the optional method gives you 25 amperes of headroom instead of 2 on the same house, with no change to the building.
• Twenty practice problems per chapter with a full answer key. Every solution shows the arithmetic, not just the result.
• Blank printable worksheets. Standard method, optional method, multifamily, and feeder calculations, ready to photocopy.
• A quick reference card. Every demand rule in the book on a single page you can keep with your tools.
• An audit checklist that catches real errors. Seven checks, plus the characteristic mistake each chapter warns about and the signature it leaves on a worksheet.
